Shenzhen Coreman Technology Co., Limited
8 Years
| Ask Lasest Price | |
| Brand Name : | Coreman |
| Model Number : | CM-P5-FS |
| Certification : | CE,ROHS,SGS,FCC |
| Price : | 200-800USD per sqm |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal |
| Supply Ability : | 5000sqm per month |
| Delivery Time : | 3-12days |
Fixed outdoor led video wall p5 outdoor led screen fix installation full color p6 p8 p10
Product Features:
1. High brightness SMD3535 2727 LED is used for outdoor LED
display, keeps the display content visible
even if facing the strong sunshine directly.
2. With Anti-UV ray mask, the color of the mask would never change
even if under exposure of UV ray.
3. Weatherproof design, completely outdoor use.
4. Easy for assembling and connection with the connector added.
5. High color uniformity and clear image can bring you a vivid
audio visual effect.
6. Rear access are available.
7. The LED Chips that we use have the advantages of large viewing
angle, low power consumption and good color
uniformity.
8. Use the same level of red, green and blue LED chips, which makes
the image display of whole LED display more
excellent and uniform.
9. The maintenance of pixel and single LED has been realized.
10. Good quality raw material, accurate technique and careful
inspection insures the high quality of LED display.
11. Relatively low cost (factory)
12. Stable capability
13. High brightness, high definition of displaying image.
14. Easy installment and low maintenance cost
15. Cabinet size double fan design, speed up internal air
circulation, auxiliary heat make the screen more stable
and reliable.
1. Competitive Price
We are middle-sized Chinese local factory, total 5 floors.
The first floor is for display testing room.
The second floor is SMT machine room.
The Third floor is for indoor led module
The Forth floor is for outdoor led module.
The fifth floor is for office
Besides, we control our cost very well and don't have huge management cost like top companies,
so that we can give the real benefits to our customers.
2. Close Relationships with Raw Material Providers
For our bosses have been in the key positions at the top LED
display factory since 2009, we have very close and strategic
relationship with the raw material providers, which support the
stable quality of our products.
3. Quality Control
From raw materials to finished product, from design to produce, we
control all steps, which are the guarantee of the quality
and reliability. All module test 2 days and all whole display test 3 days.
4. Professional services
We have 5-6 in the LED display industry more than 12 years of professional and technical personnel,
hope to be able to better provide customers with the best solution.
Let customers use the rest assured.
| Pixel pitch | 5mm | 6mm |
| Module size | 320X160mm | 192X192mm |
| Resolution | 64X32 | 32X32dots |
| Density of pixel | 40000 dots/m2 | 27777 dots/m2 |
| LED Size | SMD3535 2727 | SMD3535 2727 |
| Pixel configuration | 1R1G1B 3in1 | 1R1G1B |
| Best viewing distance | ≥5m | ≥6m |
| Horizontal viewing angle | 140º | 140º |
| Viewing angle | 140º | 140º |
| Driving method | 1/8 scan | 1/8scan |
| Brightness | 7000cd/sqm | 7000cd/m2 |
| Refresh rate | 960-1920Hz(Max 3840Hz) | 960-1920Hz(Max 3840Hz) |
| IP grade | IP65 | IP65 |
| Max power consumption | 30W/pcs | 38W/pcs |
| Avg power consumption | 18W/pcs | 20W/pcs |
| Input voltage | DC5VAC110V/220V±10% | AC110V/220V±10% DC5V |
| Storage temperature | —40°C~65°C | —40°C~65°C |
| Working temperature | —20°C~55°C | —20°C~55°C |
| MTBF | ≥10,000 hours | ≥10,000 hours |
| Life span | ≥100,000hours | ≥100,000hours |
| Control system | Nova/Linsn/Colorlight/DBstar etc | Nova/Linsn/Colorlight/DBstar etc |
| Specification might be slightly different based on different components | ||
full color fixed installation led display details
|
|
