Shenzhen Coreman Technology Co., Limited
8 Years
| Ask Lasest Price | |
| Brand Name : | COREMAN |
| Model Number : | CM-IS-P2-512mm x 512mm |
| Certification : | CE,Rohs, FCC, CCC, UL, CAS，SASO |
| Price : | 310-360USD |
| Payment Terms : | T/T, Western Union, MoneyGram, L/C |
| Supply Ability : | 50,000pcs/ month |
| Delivery Time : | 15-20 days |
256 x 256 hd led display panel , 512 x 512 480 x 480 500x500 p2 p2.87 p2.97 led rental display
P2 HD indoor led display screen , rental led panel cabinet feature:
What materials we use for the product?
1. Use high quality materials, Nicha Cree Silan Opto etc are
optional.
2. Use good quality and stable components , like MBI, Samsung etc
3. Encapsulated LEDs from Nationstar , kinglight, KN-light are
optional.
4. Famous power supply, Meanwell, Delta ,megmeet etc power supply
for high-end market customer.
What we can do ?
1. Custom or standard design led module or cabinet to meet
different customer requirement.
2. Certified product ,CCC, FCC CE -EMC, CE-LVD, Rohs,UL, CAS,SASO,
etc for differen country and market.
3. Low price on the shipping ,fast delivery to save as much time as
we can for customer.
4. 2-7 warranty according to customer situation and request.
What service we can provide
1. We will answer your inquiry with 24 hours via e-mail/ phone
,working 24 hours / 7 days.
2. We can provide the installation CAD drawing or struction for
customer as negotiation.
3. We can send engineer to customer side to install the led display
as cutomer request
4. We will provide maintenance for a lifetime and charge for the
raw materials only.
Specification:
| Pixel Pitch(W/H)mm | 2mm |
| LED Size | SMD1515 |
| Pixel Density (dots/m2) | 250,000 |
| Cabinet Size (W*H*D)mm | 512*512*65 |
| Cabinet Resolution (W*H)dots | 256*256 |
| Cabinet Weight (kg/pcs) | 6.5 |
| IP Rating ( front/back) | IP20-IP43 |
| Brightness | ≥1200cd/m2 |
| Viewing Angle (H/V) | 160°/160° |
| Viewing Distance | ≥2m |
| Gray Scale | 16bit |
| Max.Power Consumption (W/pcs) | 272 |
| Ave.PowerConsumption(W/pcs) | 90 |
| Refresh Rate | ≥1920Hz(Max 3840Hz) |
| Environment | Indoor |
| Control Mode | Synchronous display with control PC by DVI /HDMI /DP |
| Support Input | Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI |
| Operation Power | AC100~240 50/60HZ |
| Operating Temperature | -20°C~55°C(work) , - 40°C~65°C(store) |
| Operating Humidity | 10%~90% (work) , 10%~95% (store) |
| Operating Life | >100,000hours |
| Specification might be slightly different based on different components | |
Connection diagram
(Video processor is not must, it depends on the size of the display)
Application:
The led screen can be used as the indoor and outdoor stage LED display, dance floor, stadium LED display, sky backdrop curtain, fixing advertising LED display, showcase, Shopping center,stage , concert background, festival celebration , wedding, exhibition, meeting room, CCTV center ,airport , stadium games like football, basketball etc.etc. And it would be more convenient and fast .
